BSOD with new SSD :(

Discussion in 'Windows 7 Blue Screen of Death (BSOD)' started by EmptySet35, Sep 23, 2011.

  1. EmptySet35

    EmptySet35 New Member

    Joined:
    Sep 22, 2011
    Messages:
    2
    Likes Received:
    0
    So, I just installed a new Plextor 128 gig SSD (which got great reviews on newegg) and did a fresh install of windows 7 onto it, and now I get a recurring BSOD that says DRIVER_POWER_STATE_FAILURE. I attached all the required files (I think). Any ideas on what could be causing it?

    Thanks in advance!


    Attached Files:

  2. Elmer

    Elmer Extraordinary Member

    Joined:
    Mar 5, 2010
    Messages:
    3,873
    Likes Received:
    284
    Hi EmptySet35 and Welcome to The Forum.

    STOP 0x0000009F: DRIVER_POWER_STATE_FAILURE
    Usual causes:
    Device driver

    Your dump files list usbhub.sys as the probable cause. This is a Windows System file and for it to be the cause of your crash is highly unlikely.
    Old and incompatible drivers can and do cause issues with Windows 7, often giving false error codes. Random stop codes often indicate hardware issues.

    As a Priority:

    ASACPI.sys Mon Mar 28 03:30:36 2005 This driver is notorious for causing BSOD's. You have two options:
    • You can disable the ATK0110 ACPI Utility in the DeviceManager (under System Devices) with no apparent issues. OR (and if disabling does cause issues)
    • There is an update here: Asus ATK0110 driver. Look under the sub-heading: Utilities. 12th one down.
    Driver Install - Manual method

    1. Download the driver and extract it to a folder.
    2. Open the Device Manager.
    3. Right click the device you wish to change the drivers for. You can select Properties > Driver > Driver Details to check you have the right device. In this case System Devices >> ATK0110 ACPI Utility
    4. Choose Update Driver Software.
    5. Select Browse My Computer For Driver Software.
    6. Select Let me pick from a list of device drivers on my computer.
    7. Select Have disk...
    8. Select Browse..
    9. Navigate to the extracted folder and double click on the .inf file
    10. Hit OK, then Next and the driver(s) will then begin to install.
    11. After it has installed, GoTo C:\Windows\System32\Drivers. Locate the Asacpi.sys driver, right click it and check the dates under its properties. You're looking for a "Modified" date of 2009 or 2010. Occasionally it can be a bit stubborn to change.
    Make sure you have the latest firmware for your new SSD drive.

    Outdated Drivers. Update:

    GEARAspiWDM.sys Mon May 18 13:17:04 2009 Gear Software CD-ROM Class Filter Driver v4.015.1 (Feb 2010). Also comes as part of iTunes

    yk62x64.sys Wed May 20 09:14:06 2009 Marvell Yukon networking Enter Part # 88E8040 in Drivers >> Search Box. (Windows 7 & Server 2008 R2 9/15/10 v11.30.1.3)

    Drivers with Updates:

    nusb3hub.sys Fri Jan 22 03:22:18 2010
    nusb3xhc.sys Fri Jan 22 03:22:21 2010
    Go to your Motherboard Mfr. Support website and update your USB 3.0 drivers. A June 2011 set are available Here.

    RTKVHD64.sys Tue Nov 03 11:39:55 2009 Realtek HD Audio R2.65

    Bugcheck Analysis:
    Code:
    Loading Dump File [D:\DOWNLOADS\ DUMPS\EmptySet35\Seven Forums\092211-12854-01.dmp]
    Mini Kernel Dump File: Only registers and stack trace are available

    DbsSplayTreeRangeMap::Add: ignoring zero-sized range at ?fffff800`00b9c500?
    Symbol search path is: SRV*C:\Windows\WinDbgSym*http://msdl.microsoft.com/download/symbols
    Executable search path is:
    Windows 7 Kernel Version 7601 (Service Pack 1) MP (12 procs) Free x64
    Product: WinNt, suite: TerminalServer SingleUserTS
    Built by: 7601.17640.amd64fre.win7sp1_gdr.110622-1506
    Machine Name:
    Kernel base = 0xfffff800`02c56000 PsLoadedModuleList = 0xfffff800`02e9b670
    Debug session time: Thu Sep 22 23:47:27.396 2011 (UTC + 1:00)
    System Uptime: 0 days 4:34:23.752
    Loading Kernel Symbols
    ...............................................................
    ................................................................
    ................................
    Loading User Symbols
    Loading unloaded module list
    ............
    *******************************************************************************
    *                                                                             *
    *                        Bugcheck Analysis                                    *
    *                                                                             *
    *******************************************************************************

    Use !analyze -v to get detailed debugging information.

    BugCheck 9F, {3, fffffa800c113060, fffff80000b9c518, fffffa800c0b3a00}

    Unable to load image \SystemRoot\system32\DRIVERS\AiCharger.sys, Win32 error 0n2
    *** WARNING: Unable to verify timestamp for AiCharger.sys
    *** ERROR: Module load completed but symbols could not be loaded for AiCharger.sys
    Probably caused by : usbhub.sys

    Followup: MachineOwner
    ---------

    0: kd> !analyze -v
    *******************************************************************************
    *                                                                             *
    *                        Bugcheck Analysis                                    *
    *                                                                             *
    *******************************************************************************

    DRIVER_POWER_STATE_FAILURE (9f)
    A driver is causing an inconsistent power state.
    Arguments:
    Arg1: 0000000000000003, A device object has been blocking an Irp for too long a time
    Arg2: fffffa800c113060, Physical Device Object of the stack
    Arg3: fffff80000b9c518, Functional Device Object of the stack
    Arg4: fffffa800c0b3a00, The blocked IRP

    Debugging Details:
    ------------------


    DRVPOWERSTATE_SUBCODE:  3

    IMAGE_NAME:  usbhub.sys

    DEBUG_FLR_IMAGE_TIMESTAMP:  4d8c0c15

    MODULE_NAME: usbhub

    FAULTING_MODULE: fffff88006953000 usbhub

    CUSTOMER_CRASH_COUNT:  1

    DEFAULT_BUCKET_ID:  VISTA_DRIVER_FAULT

    BUGCHECK_STR:  0x9F

    PROCESS_NAME:  System

    CURRENT_IRQL:  2

    STACK_TEXT:
    fffff800`00b9c4c8 fffff800`02d40cd2 : 00000000`0000009f 00000000`00000003 fffffa80`0c113060 fffff800`00b9c518 : nt!KeBugCheckEx
    fffff800`00b9c4d0 fffff800`02cde5fc : fffff800`00b9c618 fffff800`00b9c618 00000000`00000000 00000000`00000001 : nt! ?? ::FNODOBFM::`string'+0x34a90
    fffff800`00b9c570 fffff800`02cde496 : fffffa80`0b838c68 fffffa80`0b838c68 00000000`00000000 00000000`00000000 : nt!KiProcessTimerDpcTable+0x6c
    fffff800`00b9c5e0 fffff800`02cde37e : 00000026`552952f0 fffff800`00b9cc58 00000000`00101a82 fffff800`02e4c2c8 : nt!KiProcessExpiredTimerList+0xc6
    fffff800`00b9cc30 fffff800`02cde167 : 0000000c`818b3dc3 0000000c`00101a82 0000000c`818b3d50 00000000`00000082 : nt!KiTimerExpiration+0x1be
    fffff800`00b9ccd0 fffff800`02cca96a : fffff800`02e48e80 fffff800`02e56cc0 00000000`00000000 fffff880`011784c0 : nt!KiRetireDpcList+0x277
    fffff800`00b9cd80 00000000`00000000 : fffff800`00b9d000 fffff800`00b97000 fffff800`00b9cd40 00000000`00000000 : nt!KiIdleLoop+0x5a


    STACK_COMMAND:  kb

    FOLLOWUP_NAME:  MachineOwner

    FAILURE_BUCKET_ID:  X64_0x9F_3_AiCharger_IMAGE_usbhub.sys

    BUCKET_ID:  X64_0x9F_3_AiCharger_IMAGE_usbhub.sys

    Followup: MachineOwner
    Drivers:
    Code:
    fffff880`044a6000 fffff880`044e4000   1394ohci 1394ohci.sys Sat Nov 20 10:44:56 2010 (4CE7A6A8)
    fffff880`00f5f000 fffff880`00fb6000   ACPI     ACPI.sys     Sat Nov 20 09:19:16 2010 (4CE79294)
    fffff880`044ef000 fffff880`04578000   afd      afd.sys      Mon Apr 25 03:33:58 2011 (4DB4DD96)
    fffff880`05800000 fffff880`05816000   AgileVpn AgileVpn.sys Tue Jul 14 01:10:24 2009 (4A5BCCF0)
    fffff880`00eaa000 fffff880`00eabe80   AiCharger AiCharger.sys Wed May 05 09:37:36 2010 (4BE12E50)
    fffff880`011aa000 fffff880`011b5000   amdxata  amdxata.sys  Fri Mar 19 16:18:18 2010 (4BA3A3CA)
    fffff880`05474000 fffff880`0547c000   ASACPI   ASACPI.sys   Mon Mar 28 03:30:36 2005 (42476C4C)
    fffff880`00ded000 fffff880`00df6000   atapi    atapi.sys    Tue Jul 14 00:19:47 2009 (4A5BC113)
    fffff880`010bc000 fffff880`010e6000   ataport  ataport.SYS  Sat Nov 20 09:19:15 2010 (4CE79293)
    fffff880`069c2000 fffff880`06a00000   AtihdW76 AtihdW76.sys Tue Jun 07 11:34:39 2011 (4DEDFEBF)
    fffff880`0581b000 fffff880`061f1000   atikmdag atikmdag.sys Thu Jul 28 22:29:03 2011 (4E31D49F)
    fffff880`047a6000 fffff880`047f6000   atikmpag atikmpag.sys Thu Jul 28 21:54:10 2011 (4E31CC72)
    fffff880`01858000 fffff880`0185f000   Beep     Beep.SYS     Tue Jul 14 01:00:13 2009 (4A5BCA8D)
    fffff880`04727000 fffff880`04738000   blbdrive blbdrive.sys Tue Jul 14 00:35:59 2009 (4A5BC4DF)
    fffff880`0410e000 fffff880`0412c000   bowser   bowser.sys   Wed Feb 23 04:55:04 2011 (4D649328)
    fffff880`09ab8000 fffff880`09ac8000   BthEnum  BthEnum.sys  Tue Jul 14 01:06:52 2009 (4A5BCC1C)
    fffff880`09ac8000 fffff880`09ae8000   bthpan   bthpan.sys   Tue Jul 14 01:07:00 2009 (4A5BCC24)
    fffff880`09a00000 fffff880`09a8c000   bthport  bthport.sys  Thu Apr 28 04:55:07 2011 (4DB8E51B)
    fffff880`09b74000 fffff880`09b8c000   BTHUSB   BTHUSB.sys   Thu Apr 28 04:54:56 2011 (4DB8E510)
    fffff960`00730000 fffff960`00757000   cdd      cdd.dll      unavailable (00000000)
    fffff880`06865000 fffff880`06882000   cdfs     cdfs.sys     Tue Jul 14 00:19:46 2009 (4A5BC112)
    fffff880`01825000 fffff880`0184f000   cdrom    cdrom.sys    Sat Nov 20 09:19:20 2010 (4CE79298)
    fffff880`00cff000 fffff880`00dbf000   CI       CI.dll       Sat Nov 20 13:12:36 2010 (4CE7C944)
    fffff880`01bbb000 fffff880`01beb000   CLASSPNP CLASSPNP.SYS Sat Nov 20 09:19:23 2010 (4CE7929B)
    fffff880`00ca1000 fffff880`00cff000   CLFS     CLFS.SYS     Tue Jul 14 00:19:57 2009 (4A5BC11D)
    fffff880`0152d000 fffff880`0159f000   cng      cng.sys      Sat Nov 20 10:08:45 2010 (4CE79E2D)
    fffff880`05492000 fffff880`054a2000   CompositeBus CompositeBus.sys Sat Nov 20 10:33:17 2010 (4CE7A3ED)
    fffff880`06882000 fffff880`06890000   crashdmp crashdmp.sys Tue Jul 14 01:01:01 2009 (4A5BCABD)
    fffff880`04686000 fffff880`04709000   csc      csc.sys      Sat Nov 20 09:27:12 2010 (4CE79470)
    fffff880`04709000 fffff880`04727000   dfsc     dfsc.sys     Sat Nov 20 09:26:31 2010 (4CE79447)
    fffff880`04497000 fffff880`044a6000   discache discache.sys Tue Jul 14 00:37:18 2009 (4A5BC52E)
    fffff880`01ba5000 fffff880`01bbb000   disk     disk.sys     Tue Jul 14 00:19:57 2009 (4A5BC11D)
    fffff880`0683d000 fffff880`0685f000   drmk     drmk.sys     Tue Jul 14 02:01:25 2009 (4A5BD8E5)
    fffff880`06890000 fffff880`0689a000   dump_diskdump dump_diskdump.sys Fri Apr 22 21:04:32 2011 (4DB1DF50)
    fffff880`0689a000 fffff880`068ad000   dump_dumpfve dump_dumpfve.sys Tue Jul 14 00:21:51 2009 (4A5BC18F)
    fffff880`01400000 fffff880`0148d000   dump_mv91xx dump_mv91xx.sys Wed Mar 17 07:53:06 2010 (4BA08A62)
    fffff880`0180a000 fffff880`01812000   dump_mvxxmm dump_mvxxmm.sys Wed Mar 17 07:52:37 2010 (4BA08A45)
    fffff880`06ff0000 fffff880`06ffc000   Dxapi    Dxapi.sys    Tue Jul 14 00:38:28 2009 (4A5BC574)
    fffff880`054a2000 fffff880`05596000   dxgkrnl  dxgkrnl.sys  Sat Nov 20 09:50:50 2010 (4CE799FA)
    fffff880`05596000 fffff880`055dc000   dxgmms1  dxgmms1.sys  Sat Nov 20 09:49:53 2010 (4CE799C1)
    fffff880`0104c000 fffff880`01060000   fileinfo fileinfo.sys Tue Jul 14 00:34:25 2009 (4A5BC481)
    fffff880`01000000 fffff880`0104c000   fltmgr   fltmgr.sys   Sat Nov 20 09:19:24 2010 (4CE7929C)
    fffff880`015b0000 fffff880`015ba000   Fs_Rec   Fs_Rec.sys   Tue Jul 14 00:19:45 2009 (4A5BC111)
    fffff880`01b6b000 fffff880`01ba5000   fvevol   fvevol.sys   Sat Nov 20 09:24:06 2010 (4CE793B6)
    fffff880`01a68000 fffff880`01ab2000   fwpkclnt fwpkclnt.sys Sat Nov 20 09:21:37 2010 (4CE79321)
    fffff880`0547c000 fffff880`05489000   GEARAspiWDM GEARAspiWDM.sys Mon May 18 13:17:04 2009 (4A1151C0)
    fffff800`02c0d000 fffff800`02c56000   hal      hal.dll      Sat Nov 20 13:00:25 2010 (4CE7C669)
    fffff880`055dc000 fffff880`05600000   HDAudBus HDAudBus.sys Sat Nov 20 10:43:42 2010 (4CE7A65E)
    fffff880`09b59000 fffff880`09b61000   hiber_mvxxmm hiber_mvxxmm.sys Wed Mar 17 07:52:37 2010 (4BA08A45)
    fffff880`029a7000 fffff880`029c0000   HIDCLASS HIDCLASS.SYS Sat Nov 20 10:43:49 2010 (4CE7A665)
    fffff880`029c0000 fffff880`029c8080   HIDPARSE HIDPARSE.SYS Tue Jul 14 01:06:17 2009 (4A5BCBF9)
    fffff880`02999000 fffff880`029a7000   hidusb   hidusb.sys   Sat Nov 20 10:43:49 2010 (4CE7A665)
    fffff880`04045000 fffff880`0410e000   HTTP     HTTP.sys     Sat Nov 20 09:24:30 2010 (4CE793CE)
    fffff880`01b62000 fffff880`01b6b000   hwpolicy hwpolicy.sys Sat Nov 20 09:18:54 2010 (4CE7927E)
    fffff880`0475e000 fffff880`04774000   intelppm intelppm.sys Tue Jul 14 00:19:25 2009 (4A5BC0FD)
    fffff880`01200000 fffff880`0120f000   kbdclass kbdclass.sys Tue Jul 14 00:19:50 2009 (4A5BC116)
    fffff880`029c9000 fffff880`029d7000   kbdhid   kbdhid.sys   Sat Nov 20 10:33:25 2010 (4CE7A3F5)
    fffff800`00bd1000 fffff800`00bdb000   kdcom    kdcom.dll    Sat Feb 05 16:52:49 2011 (4D4D8061)
    fffff880`068e6000 fffff880`06929000   ks       ks.sys       Sat Nov 20 10:33:23 2010 (4CE7A3F3)
    fffff880`01512000 fffff880`0152d000   ksecdd   ksecdd.sys   Sat Nov 20 09:21:15 2010 (4CE7930B)
    fffff880`017d3000 fffff880`017fe000   ksecpkg  ksecpkg.sys  Sat Nov 20 10:10:34 2010 (4CE79E9A)
    fffff880`0685f000 fffff880`06864200   ksthunk  ksthunk.sys  Tue Jul 14 01:00:19 2009 (4A5BCA93)
    fffff880`0285c000 fffff880`02871000   lltdio   lltdio.sys   Tue Jul 14 01:08:50 2009 (4A5BCC92)
    fffff880`02938000 fffff880`0295b000   luafv    luafv.sys    Tue Jul 14 00:26:13 2009 (4A5BC295)
    fffff880`00c3e000 fffff880`00c8d000   mcupdate_GenuineIntel mcupdate_GenuineIntel.dll Sat Nov 20 13:03:51 2010 (4CE7C737)
    fffff880`068ad000 fffff880`068bb000   monitor  monitor.sys  Tue Jul 14 00:38:52 2009 (4A5BC58C)
    fffff880`011b5000 fffff880`011c4000   mouclass mouclass.sys Tue Jul 14 00:19:50 2009 (4A5BC116)
    fffff880`0810d000 fffff880`0811a000   mouhid   mouhid.sys   Tue Jul 14 01:00:20 2009 (4A5BCA94)
    fffff880`00dbf000 fffff880`00dd9000   mountmgr mountmgr.sys Sat Nov 20 09:19:21 2010 (4CE79299)
    fffff880`01600000 fffff880`01631000   MpFilter MpFilter.sys Wed Apr 06 21:07:29 2011 (4D9CC801)
    fffff880`080fd000 fffff880`0810d000   MpNWMon  MpNWMon.sys  Wed Apr 06 21:07:23 2011 (4D9CC7FB)
    fffff880`0412c000 fffff880`04144000   mpsdrv   mpsdrv.sys   Tue Jul 14 01:08:25 2009 (4A5BCC79)
    fffff880`04144000 fffff880`04171000   mrxsmb   mrxsmb.sys   Wed Apr 27 03:40:38 2011 (4DB78226)
    fffff880`04171000 fffff880`041bf000   mrxsmb10 mrxsmb10.sys Sat Jul 09 03:46:28 2011 (4E17C104)
    fffff880`041bf000 fffff880`041e3000   mrxsmb20 mrxsmb20.sys Wed Apr 27 03:39:37 2011 (4DB781E9)
    fffff880`0149f000 fffff880`014aa000   Msfs     Msfs.SYS     Tue Jul 14 00:19:47 2009 (4A5BC113)
    fffff880`00fbf000 fffff880`00fc9000   msisadrv msisadrv.sys Tue Jul 14 00:19:26 2009 (4A5BC0FE)
    fffff880`014b4000 fffff880`01512000   msrpc    msrpc.sys    Sat Nov 20 09:21:56 2010 (4CE79334)
    fffff880`0448c000 fffff880`04497000   mssmbios mssmbios.sys Tue Jul 14 00:31:10 2009 (4A5BC3BE)
    fffff880`01b50000 fffff880`01b62000   mup      mup.sys      Tue Jul 14 00:23:45 2009 (4A5BC201)
    fffff880`010e6000 fffff880`01173000   mv91xx   mv91xx.sys   Wed Mar 17 07:53:06 2010 (4BA08A62)
    fffff880`011a2000 fffff880`011aa000   mvxxmm   mvxxmm.sys   Wed Mar 17 07:52:37 2010 (4BA08A45)
    fffff880`01680000 fffff880`01773000   ndis     ndis.sys     Sat Nov 20 09:23:30 2010 (4CE79392)
    fffff880`061f1000 fffff880`061fd000   ndistapi ndistapi.sys Tue Jul 14 01:10:00 2009 (4A5BCCD8)
    fffff880`01060000 fffff880`0108f000   ndiswan  ndiswan.sys  Sat Nov 20 10:52:32 2010 (4CE7A870)
    fffff880`069ad000 fffff880`069c2000   NDProxy  NDProxy.SYS  Sat Nov 20 10:52:20 2010 (4CE7A864)
    fffff880`045ec000 fffff880`045fb000   netbios  netbios.sys  Tue Jul 14 01:09:26 2009 (4A5BCCB6)
    fffff880`04578000 fffff880`045bd000   netbt    netbt.sys    Sat Nov 20 09:23:18 2010 (4CE79386)
    fffff880`01773000 fffff880`017d3000   NETIO    NETIO.SYS    Sat Nov 20 09:23:13 2010 (4CE79381)
    fffff880`0811a000 fffff880`08132000   NisDrvWFP NisDrvWFP.sys Wed Apr 06 21:08:53 2011 (4D9CC855)
    fffff880`015ba000 fffff880`015cb000   Npfs     Npfs.SYS     Tue Jul 14 00:19:48 2009 (4A5BC114)
    fffff880`04480000 fffff880`0448c000   nsiproxy nsiproxy.sys Tue Jul 14 00:21:02 2009 (4A5BC15E)
    fffff800`02c56000 fffff800`0323f000   nt       ntkrnlmp.exe Thu Jun 23 03:53:23 2011 (4E02AAA3)
    fffff880`0121a000 fffff880`013bd000   Ntfs     Ntfs.sys     Fri Mar 11 03:39:39 2011 (4D79997B)
    fffff880`0184f000 fffff880`01858000   Null     Null.SYS     Tue Jul 14 00:19:37 2009 (4A5BC109)
    fffff880`0693b000 fffff880`06953000   nusb3hub nusb3hub.sys Fri Jan 22 03:22:18 2010 (4B5919EA)
    fffff880`04774000 fffff880`047a4000   nusb3xhc nusb3xhc.sys Fri Jan 22 03:22:21 2010 (4B5919ED)
    fffff880`045c6000 fffff880`045ec000   pacer    pacer.sys    Sat Nov 20 10:52:18 2010 (4CE7A862)
    fffff880`00e0d000 fffff880`00e22000   partmgr  partmgr.sys  Sat Nov 20 09:20:00 2010 (4CE792C0)
    fffff880`00fc9000 fffff880`00ffc000   pci      pci.sys      Sat Nov 20 09:19:11 2010 (4CE7928F)
    fffff880`00e93000 fffff880`00e9a000   pciide   pciide.sys   Tue Jul 14 00:19:49 2009 (4A5BC115)
    fffff880`00e9a000 fffff880`00eaa000   PCIIDEX  PCIIDEX.SYS  Tue Jul 14 00:19:48 2009 (4A5BC114)
    fffff880`0159f000 fffff880`015b0000   pcw      pcw.sys      Tue Jul 14 00:19:27 2009 (4A5BC0FF)
    fffff880`070e6000 fffff880`0718c000   peauth   peauth.sys   Tue Jul 14 02:01:19 2009 (4A5BD8DF)
    fffff880`06800000 fffff880`0683d000   portcls  portcls.sys  Tue Jul 14 01:06:27 2009 (4A5BCC03)
    fffff880`00c8d000 fffff880`00ca1000   PSHED    PSHED.dll    Tue Jul 14 02:32:23 2009 (4A5BE027)
    fffff880`013bd000 fffff880`013e1000   rasl2tp  rasl2tp.sys  Sat Nov 20 10:52:34 2010 (4CE7A872)
    fffff880`04664000 fffff880`0467f000   raspppoe raspppoe.sys Tue Jul 14 01:10:17 2009 (4A5BCCE9)
    fffff880`0108f000 fffff880`010b0000   raspptp  raspptp.sys  Sat Nov 20 10:52:31 2010 (4CE7A86F)
    fffff880`013e1000 fffff880`013fb000   rassstp  rassstp.sys  Tue Jul 14 01:10:25 2009 (4A5BCCF1)
    fffff880`0442f000 fffff880`04480000   rdbss    rdbss.sys    Sat Nov 20 09:27:51 2010 (4CE79497)
    fffff880`044e4000 fffff880`044ef000   rdpbus   rdpbus.sys   Tue Jul 14 01:17:46 2009 (4A5BCEAA)
    fffff880`01674000 fffff880`0167d000   RDPCDD   RDPCDD.sys   Tue Jul 14 01:16:34 2009 (4A5BCE62)
    fffff880`0148d000 fffff880`01496000   rdpencdd rdpencdd.sys Tue Jul 14 01:16:34 2009 (4A5BCE62)
    fffff880`01496000 fffff880`0149f000   rdprefmp rdprefmp.sys Tue Jul 14 01:16:35 2009 (4A5BCE63)
    fffff880`01b16000 fffff880`01b50000   rdyboost rdyboost.sys Sat Nov 20 09:43:10 2010 (4CE7982E)
    fffff880`09a8c000 fffff880`09ab8000   rfcomm   rfcomm.sys   Tue Jul 14 01:06:56 2009 (4A5BCC20)
    fffff880`02871000 fffff880`02889000   rspndr   rspndr.sys   Tue Jul 14 01:08:50 2009 (4A5BCC92)
    fffff880`06e03000 fffff880`06fef780   RTKVHD64 RTKVHD64.sys Tue Nov 03 11:39:55 2009 (4AF0168B)
    fffff880`01173000 fffff880`011a2000   SCSIPORT SCSIPORT.SYS Sat Nov 20 10:34:01 2010 (4CE7A419)
    fffff880`0718c000 fffff880`07197000   secdrv   secdrv.SYS   Wed Sep 13 14:18:38 2006 (4508052E)
    fffff880`01b0e000 fffff880`01b16000   spldr    spldr.sys    Mon May 11 17:56:27 2009 (4A0858BB)
    fffff880`08132000 fffff880`081a3000   spsys    spsys.sys    Mon May 11 18:20:58 2009 (4A085E7A)
    fffff880`08065000 fffff880`080fd000   srv      srv.sys      Fri Apr 29 04:06:06 2011 (4DBA2B1E)
    fffff880`07000000 fffff880`07069000   srv2     srv2.sys     Fri Apr 29 04:05:46 2011 (4DBA2B0A)
    fffff880`07197000 fffff880`071c8000   srvnet   srvnet.sys   Fri Apr 29 04:05:35 2011 (4DBA2AFF)
    fffff880`061fd000 fffff880`061fe480   swenum   swenum.sys   Tue Jul 14 01:00:18 2009 (4A5BCA92)
    fffff880`01864000 fffff880`01a68000   tcpip    tcpip.sys    Tue Jun 21 04:33:55 2011 (4E001123)
    fffff880`071c8000 fffff880`071da000   tcpipreg tcpipreg.sys Sat Nov 20 10:51:48 2010 (4CE7A844)
    fffff880`015ed000 fffff880`015fa000   TDI      TDI.SYS      Sat Nov 20 09:22:06 2010 (4CE7933E)
    fffff880`015cb000 fffff880`015ed000   tdx      tdx.sys      Sat Nov 20 09:21:54 2010 (4CE79332)
    fffff880`0441b000 fffff880`0442f000   termdd   termdd.sys   Sat Nov 20 11:03:40 2010 (4CE7AB0C)
    fffff960`004c0000 fffff960`004ca000   TSDDD    TSDDD.dll    unavailable (00000000)
    fffff880`04738000 fffff880`0475e000   tunnel   tunnel.sys   Sat Nov 20 10:51:50 2010 (4CE7A846)
    fffff880`06929000 fffff880`0693b000   umbus    umbus.sys    Sat Nov 20 10:44:37 2010 (4CE7A695)
    fffff880`0297c000 fffff880`02999000   usbccgp  usbccgp.sys  Fri Mar 25 03:29:14 2011 (4D8C0C0A)
    fffff880`047a4000 fffff880`047a5f00   USBD     USBD.SYS     Fri Mar 25 03:28:59 2011 (4D8C0BFB)
    fffff880`05463000 fffff880`05474000   usbehci  usbehci.sys  Fri Mar 25 03:29:04 2011 (4D8C0C00)
    fffff880`06953000 fffff880`069ad000   usbhub   usbhub.sys   Fri Mar 25 03:29:25 2011 (4D8C0C15)
    fffff880`0540d000 fffff880`05463000   USBPORT  USBPORT.SYS  Fri Mar 25 03:29:12 2011 (4D8C0C08)
    fffff880`05400000 fffff880`0540d000   usbuhci  usbuhci.sys  Fri Mar 25 03:29:03 2011 (4D8C0BFF)
    fffff880`00e00000 fffff880`00e0d000   vdrvroot vdrvroot.sys Tue Jul 14 01:01:31 2009 (4A5BCADB)
    fffff880`01631000 fffff880`0163f000   vga      vga.sys      Tue Jul 14 00:38:47 2009 (4A5BC587)
    fffff880`0163f000 fffff880`01664000   VIDEOPRT VIDEOPRT.SYS Tue Jul 14 00:38:51 2009 (4A5BC58B)
    fffff880`00c00000 fffff880`00c3c000   vmbus    vmbus.sys    Sat Nov 20 09:57:29 2010 (4CE79B89)
    fffff880`01ab2000 fffff880`01ac2000   vmstorfl vmstorfl.sys Sat Nov 20 09:57:30 2010 (4CE79B8A)
    fffff880`00e22000 fffff880`00e37000   volmgr   volmgr.sys   Sat Nov 20 09:19:28 2010 (4CE792A0)
    fffff880`00e37000 fffff880`00e93000   volmgrx  volmgrx.sys  Sat Nov 20 09:20:43 2010 (4CE792EB)
    fffff880`01ac2000 fffff880`01b0e000   volsnap  volsnap.sys  Sat Nov 20 09:20:08 2010 (4CE792C8)
    fffff880`04400000 fffff880`0441b000   wanarp   wanarp.sys   Sat Nov 20 10:52:36 2010 (4CE7A874)
    fffff880`01664000 fffff880`01674000   watchdog watchdog.sys Tue Jul 14 00:37:35 2009 (4A5BC53F)
    fffff880`00eac000 fffff880`00f50000   Wdf01000 Wdf01000.sys Tue Jul 14 00:22:07 2009 (4A5BC19F)
    fffff880`00f50000 fffff880`00f5f000   WDFLDR   WDFLDR.SYS   Tue Jul 14 00:19:54 2009 (4A5BC11A)
    fffff880`045bd000 fffff880`045c6000   wfplwf   wfplwf.sys   Tue Jul 14 01:09:26 2009 (4A5BCCB6)
    fffff960`00010000 fffff960`00323000   win32k   win32k.sys   unavailable (00000000)
    fffff880`00dd9000 fffff880`00ded000   winhv    winhv.sys    Sat Nov 20 09:20:02 2010 (4CE792C2)
    fffff880`05489000 fffff880`05492000   wmiacpi  wmiacpi.sys  Tue Jul 14 00:31:02 2009 (4A5BC3B6)
    fffff880`00fb6000 fffff880`00fbf000   WMILIB   WMILIB.SYS   Tue Jul 14 00:19:51 2009 (4A5BC117)
    fffff880`0295b000 fffff880`0297c000   WudfPf   WudfPf.sys   Sat Nov 20 10:42:44 2010 (4CE7A624)
    fffff880`04600000 fffff880`04664000   yk62x64  yk62x64.sys  Wed May 20 09:14:06 2009 (4A13BBCE)

    Unloaded modules:
    fffff880`028ac000 fffff880`02938000   bthport.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0008C000
    fffff880`068bb000 fffff880`068d3000   BTHUSB.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  00018000
    fffff880`0282c000 fffff880`0283c000   BthEnum.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  00010000
    fffff880`02800000 fffff880`0282c000   rfcomm.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0002C000
    fffff880`0283c000 fffff880`0285c000   bthpan.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  00020000
    fffff880`081a3000 fffff880`081ad000   hiber_scsipo
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0000A000
    fffff880`09acc000 fffff880`09b59000   hiber_mv91xx
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0008D000
    fffff880`09b61000 fffff880`09b74000   hiber_dumpfv
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  00013000
    fffff880`01beb000 fffff880`01bf9000   crashdmp.sys
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0000E000
    fffff880`01800000 fffff880`0180a000   dump_scsipor
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0000A000
    fffff880`01400000 fffff880`0148d000   dump_mv91xx.
        Timestamp: unavailable (00000000)
        Checksum:  00000000
        ImageSize:  0008D000
    fffff880`01812000 fffff880`01825000   dump_dumpfve
        Timestamp: unavailable (00000000)
        Checksum:  00000000
    Let us know how it goes. If you get further problems with blue screens, attach your new dump files and details and we'll move on from there.


    HTH.

    1 person likes this.

Share This Page

Loading...
