If the taskbar or other desktop edges disappear beyond your TV screen, set the TV to show the full incoming picture, then check that Windows is using the appropriate display resolution. If the TV has no suitable picture-size control, use the connected graphics processor’s resize or scaling controls. These steps apply to Windows 11 and Windows 10 with a TV connected as an external display, typically over HDMI.

The usual cause is overscan: the TV enlarges the picture slightly, hiding its outer edges. The opposite problem, a picture surrounded by an unwanted black border, is called underscan. Fixing the TV setting first usually preserves the sharpest desktop image; GPU resizing is a useful fallback.

A man adjusts display settings on his laptop, mirrored on a large TV in his living room. Before changing the picture​

Quick walkthrough

  • Turn on the TV and select the HDMI input connected to the PC. Keep the TV remote handy: its picture settings are separate from Windows settings.
  • If possible, connect the PC directly to the TV while testing. A dock, receiver, adapter or video processor between them can affect the signal or add its own picture controls.
  • Note the current Windows resolution and the TV’s current picture-size setting before changing them. If you use a GPU slider, note its starting position too.
  • If you have a laptop or second monitor, leave it connected during testing so you have another screen to use if a setting makes the TV temporarily unreadable.
  • No restart is normally needed for the picture-size and scaling adjustments in this guide.

Before changing resolution or refresh rate: the TV may briefly go blank or reject the new signal. Windows normally asks you to confirm a display change; if you cannot see the confirmation, wait without accepting it so the previous setting can return. Use your other screen if available.

1. Select the TV and check its resolution​

Windows 11 Settings app on the System > Display page showing the Scale and Display resolution controls (a virtual machine has no brightness slider)

  • Press Windows + I to open Settings, then choose System > Display.
  • If more than one screen appears at the top, select Identify. A number appears on each display. Select the numbered rectangle corresponding to the TV before changing its settings.
  • If Windows is duplicating the same desktop on a laptop and TV, consider testing with separate displays:
  • Press Windows + P.
  • Select Extend, then return to Settings > System > Display and select the TV again.

Extend lets you adjust the TV as a separate display. You can return to Duplicate later with Windows + P, although you should recheck the picture after doing so.

  • Under Scale & layout, find Display resolution. Select the resolution marked Recommended and confirm the change if the picture is usable. If it is already selected, leave it in place.
  • Check the result before changing anything else. If the desktop still runs past the edges, continue to the TV controls below.

The recommended resolution is a good starting point, but it is not a substitute for correcting overscan. If you know the TV’s native resolution from its manual, check that the selected resolution is appropriate for the TV and the HDMI input being used. A lower resolution can make text less sharp or introduce borders.

Do not confuse Display resolution with Windows Scale. Scale changes the size of text and apps; it does not normally fix a TV that is cropping the outside of the desktop. You can adjust text size after the whole desktop is visible.

2. Turn off overscan on the TV​

TV menu names vary by manufacturer and model. Use the remote while the PC’s HDMI input is selected; a setting changed for another input may not affect the PC.

  • Open the TV’s settings or picture menu. Look for a control named Picture, Aspect, Format, Picture Size, HD Size or Display Area. It may be inside an advanced picture submenu.
  • Look for a full-picture option such as 1:1, Just Scan, Full Pixel, Unscaled or Screen Fit. Select the option your TV offers. These are examples, not labels every TV will have.
  • If the TV offers a choice specifically for overscan, turn overscan off.
  • Look at all four desktop edges. The taskbar and its contents should be fully visible, and the picture should reach the viewable screen edges without an unintended border.
  • If the first option does not fit, try the TV’s other relevant picture-size or display-area choices one at a time. Give the picture a moment to settle after each change.

Some TVs also allow an input to be identified as a PC input. If the TV manual describes that option, try it for the HDMI input connected to the computer, then check the picture-size setting again. The exact menu and available choices depend on the TV.

If the TV setting fixes the crop, stop here and verify the result in the next section. If the TV has no suitable control, or the edges remain cut off after adjustment, use the GPU method below.

3. Verify the desktop fits​

  • Return to the desktop and check the top, bottom, left and right edges. The taskbar should be entirely visible rather than disappearing below or beside the screen.
  • Open a window and maximize it. Its title bar and window controls should remain visible.
  • Move the mouse pointer toward each edge. Confirm that the picture is not visibly cropped and that there is no unwanted black frame around all four sides.
  • Open Settings > System > Display, select the TV and confirm that the resolution remains the one you intended to use.
  • If you normally use Duplicate rather than Extend, switch back with Windows + P and check the TV again. If the crop returns in Duplicate mode, use Extend while troubleshooting and check the TV’s resolution and picture setting in the mode you intend to keep.

A movie can have black bars as part of its presentation, so judge the desktop and a maximized window rather than a single video. If only one game or app is cropped while the Windows desktop fits, inspect that app’s display or resolution settings before changing the entire TV picture.

4. Resize with the graphics software if necessary​

Use one of the following methods for the graphics hardware that controls the TV output. The available app and controls depend on the PC, driver, display connection and hardware. On a laptop with more than one GPU, the GPU used to render an app is not necessarily the one controlling the TV connector.

To see the installed graphics adapters, search Windows for Device Manager, open it and expand Display adapters. If more than one adapter is listed, a vendor’s display controls may appear only when that GPU controls the connected output.

GPU resizing can trade some sharpness for a complete picture. Record the original settings before changing them so you can reverse the adjustment if the TV’s own controls later provide a better fit.

NVIDIA Control Panel​

  • Open NVIDIA Control Panel.
  • In the navigation tree, choose Display > Adjust desktop size and position. Select the TV if the page offers a display selection.
  • Open the Size tab. If it is not present, the resize feature may not be available for that display or connection.
  • Select Enable desktop resizing, then click Resize.
  • Move the sliders until the desktop fits inside the visible screen. Click OK.

NVIDIA notes that this operation applies a resized resolution and adds it to the available resolution list. If a game later uses a different resolution or refresh rate, check its picture separately; the desktop adjustment may not carry over as expected.

To undo the adjustment, return to the Size tab and clear Enable desktop resizing, then select the original resolution and refresh rate if necessary. You can also return to Settings > System > Display and select the TV’s intended resolution.

AMD Software: Adrenalin Edition​

  • Open Start, search for AMD Software and launch it.
  • In the app’s search box, enter Display, then select Display Settings.
  • If multiple displays are shown, select the TV.
  • Find HDMI Scaling and move its slider until the desktop fits. AMD identifies 0% as the default position in its documented example.
  • Check all four edges. If the picture still does not fit, revisit the TV’s on-screen picture-size menu; AMD suggests checking for Auto or Just Scan where available.

If HDMI Scaling is missing or unavailable, confirm that the output and display are compatible and that the resolution and refresh rate match those specified for the TV’s HDMI input. The supported AMD graphics driver must also be installed. The control is not guaranteed to appear in every configuration.

To roll back, return the slider to its recorded starting value, or to 0% if that was the original value.

Intel Graphics Command Center​

  • Open Windows search, enter Intel Graphics Command Center and launch the app.
  • Select Display in the left navigation.
  • Select the TV that has the cropped picture.
  • On the General tab, find Scale and select Custom from the drop-down menu.
  • Adjust the two sliders until the desktop fits, then close the window and check all four edges.

Intel says custom scaling is available only for external displays; the option may also be absent on a particular driver or configuration. To reverse the change, return to Scale and select the option you recorded before choosing Custom.

Fix common problems​

The TV is not listed in Display settings​

Check that the TV is on the correct HDMI input and that the cable is firmly connected. Press Windows + P and choose Extend.

In Windows 11, open Settings > System > Display > Multiple displays and select Detect. In Windows 10, open Settings > System > Display and look under Multiple displays for Detect. If detection still fails, test a direct connection without a dock, receiver or adapter where practical, or try another cable or TV input.

The AMD slider is unavailable​

Check the resolution first, then the refresh rate specified for the TV’s HDMI input. The Windows paths differ:

  • Windows 11: Settings > System > Display > Advanced display. Select the TV, then use Choose a refresh rate.
  • Windows 10: Settings > System > Display > Advanced display settings. Select the TV, then use Refresh rate.

Choose a rate supported by the TV and connection; do not assume the highest listed rate is required. Note the previous rate so you can restore it. After a change, confirm the resolution has not also changed. Return to AMD Software and check whether HDMI Scaling is available.

A GPU display or resize option is missing​

First confirm that the TV is detected by Windows and that you selected it in the graphics app. The app may not control the physical output, or its driver or hardware may not expose that feature. Try the TV’s own picture-size controls and, if practical, a direct connection. For a laptop or dock, consult its manufacturer for the supported display driver and output configuration.

Avoid creating a custom resolution or changing undocumented timing values just to find the desktop edges; the ordinary TV and vendor resize controls are the safer starting points.

The picture now has a black border or looks soft​

A GPU adjustment may have shrunk the image too far, or a non-native resolution may have been selected. Reduce or undo the GPU adjustment, check the Windows resolution, and revisit the TV’s full-picture setting. Make one change at a time and check all four edges after each one.

The problem began after a graphics update​

Device Manager showing the computer's hardware device categories in a tree.

First recheck the selected TV, resolution, TV picture mode and GPU scaling setting. If an available driver update is appropriate, Windows Update or the PC manufacturer’s support documentation can provide it.

If the crop began immediately after a driver update and the previous driver worked, Windows may offer a rollback:

  • Search for and open Device Manager.
  • Expand Display adapters, right-click the relevant adapter and select Properties.
  • Open the Driver tab and select Roll Back Driver if it is available.

A driver change can briefly interrupt the display and may require a restart. Keep a second screen available if possible, and follow the prompts. Afterward, repeat the desktop-edge checks.

If the picture is still cropped after testing the TV controls, resolution and available GPU adjustment, record the TV model, HDMI input, PC or GPU model, resolution, refresh rate and connection path. Use those details when checking the TV or PC manufacturer’s support documentation: the remaining limitation may be specific to that input, adapter or display mode.
